Multi-Port Centralized Lubrication System
| Model | Part Number |
|---|---|
| YMT-C-E-S-AC | 300421 |
| PowerVoltage | AC100V-AC240V 50/60Hz |
| Current value Discharge control |
** A (during Pump operation) 0.55 to 1.44A Switch time, count by select switch |
| Discharge time | 1 to 99 minutes (1-minute step) |
| Discharge count number | 1 to 99 counts (1-count step) |
| Interval | 1 to 99 hours (1-hour step) |
| Alarm Detection | - Grease Level - No Cartridge - Pressure Alarm - Valve Malfunction (Count Mode only) |
| Alarm Signal Output | AContact, BContact Not Rated: 200V 2A or less |
| Input Signal | Number of proximity switch inputs: 1 to 5 |
| Power failure memory | lash memory |
| Protection Class | IP65 |
